Stadium 974, Doha

Fenwick Iribarren Architects


Since their invention and standardization in the mid-20th century, metallic containers have optimized shipping transportation, ushering in a new era of global logistics and commercial exchange. Later on, new approaches to architectural seriation and the recycling of industrial components encouraged the reuse of these functional storage units in civil works. All of these factors, along with others like shorter construction time, a low ecological footprint, and the potential reversibility led to the design of Stadium 974 for Qatar 2022 World Cup, which codifies each one of the elements used – including its 974 containers – to ensure they can be taken apart and converted into up to five sports facilities.

The stadium goes up by the main port of the capital of Qatar. This location inspired a ‘facadeless’ construction using 974 recycled shipping containers to favor natural ventilation and reduce the need for climate control systems.

The project gives a new value to the characteristic chromatic palette of ports and transport centers, associating the bright colors of shipping containers to the different functional programs of the stadium, making them recognizable for spectators.

Each one of the elements used have followed a stringent standardization process to later be codified and identified – by section, level or orientation – and to make tasks such as transportation, storage, and assembly easier.

The stadium’s structure is designed as a huge meccano, following principles of seriation with prefabricated slabs and metal supports; reversibility, using screwed or dry joinery; and sustainability, using recycled steel.

All the elements follow the ‘plug and play’ strategy that permits their prefabrication – even the interior installations and finishes are built in a workshop – and later connection to the general net, allowing in this way to reduce construction time and cost.

Once the Qatar World Cup is over it will be possible to take the stadium apart entirely and move it to a different location or adapt it to other events. Venues such as athletics tracks, sports centers or swimming pools have been designed with the same components...[+]


Obra Work
Estadio 974, Doha (Catar)
Stadium 974, Doha (Qatar)

ClienteClient
Supreme Committee for Delivery and Legacy

ArquitectosAchitects
Fenwick Iribarren Architects

EquipoTeam
Mark Fenwick, Javier Iribarren (socios partners), Olga Redondo (director de proyecto project director), Javier Iribarren Jr, Alejandra Fenwick, Javier Pérez, Borja Gómez, Lucas Soto (arquitectos architects), Isabel Ruiz (diseño de interiores interior design), Carlos Chamorro (paisajismo landscaping), José Manuel Fernández (arquitecto local site architect), Laura Carrero, Pedro Orquín, Sebastian Franco (arquitectos BIM BIM architect)

ColaboradoresCollaborators
Knut Stockhusen / Schlaich Bergermann & Partners (estructura structure); Tony Morris / Hilson Moran (instalaciones mechanical engineering); Niall Keogh / Exova (especialista en fuego fire consultant); John Downman /Tricon (especialistas en restauración y gestión de residuos food & beverage and waste strategy); Ruben Reddy (especialista en infraestructuras temporales overlay consultant), Luis Molinelli / Eurisko (simulación de multitudes crowd modelling); Víctor Soria / LDC (iluminación fachada facade lighting); Ignacio Urbina (señalética signage); Jorge Queipo / Queipo maquetas (maquetas models); Juan Llamazares (vídeos films)

FotografíaPhotographs
Todas las imágenes recogidas en este capítulo son cortesía de Fenwick Iribarren Architects 
All the images in this chapter are courtesy of Fenwick Iribarren Architects
